BGA mount
BGA mount
With the continuous increase of information processing capacity and the improvement of chip computing speed, more and more BGA packaging form of high integration is used in the field of IC packaging, and the corresponding BGA Pad on PCB also appears in a large scale, an IC BGA solder joint and the corresponding Pad often reach hundreds or even thousands. The reliability of welding at every point becomes more and more important and becomes the key to the yield of BGA mounting. Plasma surface treatment on PCB Pad before BGA installation can achieve the effect of cleaning, coarsing and activating the Pad surface, which greatly improves the success rate of BGA installation.
Soft and hard combined board
Soft and hard combined board
Because the soft and hard bonded plate is composed of several different materials laminated together, due to the inconsistency of its thermal expansion coefficient, the hole wall and the line connection between layers are prone to fracture and tear phenomenon, improve the reliability of the soft and hard bonded plate hole metallization and the bonding force between the line lamination, is the key technology of the soft and hard bonded plate quality. The traditional process uses chemical potions wet process, the characteristics of the potions are not strong acid or strong alkaline, which will be adverse to polyimide resin, acrylic resin and so on. The dry treatment technology using plasma to clean, coarser and activate the material surface can not only obtain good reliability and binding force, but also overcome the defects of the traditional process and realize the green environmental protection process without emission.
HDI board
HDI board
HDI is a high density interconnected circuit board, after low temperature plasma treatment can effectively remove the carbide after laser drilling, play the effect of liquid medicine can not be thoroughly purified, can clean the hole wall and hole bottom after laser drilling, coarsing and activating treatment, greatly improve the yield and reliability of laser drilling PTH process, overcome the copper plating layer and hole bottom cracks.
FPC board
FPC board
The main material of FPC printed circuit board (soft board) is composed of polyimide resin. Due to the heat generated during drilling, it is easy to leave a large amount of resin glue residue in the hole, resulting in poor connection between the copper plating layer of the hole wall and the inner line, and even open circuit fracture phenomenon. Currently, resin swelling agent and potassium permanganate potion are commonly used in the industry to remove the glue residue in the hole. Potassium permanganate has great destructive effect on polyimide resin properties. The low temperature plasma treatment can effectively remove the residual glue of the hole wall, and achieve the effect of cleaning, activation and uniform etching, which is conducive to the connection between the inner line and the copper plating layer of the hole wall, and enhance the binding force. Plasma treatment before chemical plating and electric plating can effectively remove the dirt on the surface of the pad and eliminate leakage plating. Before SMT, plasma treatment can effectively remove the dirt on the pad surface and eliminate virtual welding.
